Digitales Oberflächenmodell DOM (roh) 2001

Mittels Laserscanningverfahren 2001/2002 erfasstes Oberflächenmodell (inkl. Bewuchs und Gebäude) über ganz Liechtenstein. Der Datensatz besteht aus Einzelpunkten mit einer Punktdichte von ca. 1 Punkt pro 2 m2. Die Genauigkeit der Einzelpunkthöhen beträgt ca. ±0.5 m ( ± 1.5 m im Vegetationsbereich).

Date (Creation): 2002-01-01

Citation identifier: https://metadata.geo.llv.li/7e312168-ea61-46d1-80fc-0db12742f046

Purpose: Grundlagedaten, Höheninformationen

Status: Completed

Point of contact

Organisation name	Individual name	Electronic mail address	Role
Civil Engineering and Geoinformation Office		info.atg@llv.li	Point of contact

Maintenance and update frequency: Unknown

Resource format

Name	Version
GRID ASCII (XYZ)

geocat.ch

INSPIRE
DSM (digital surface model)

GEMET - INSPIRE themes, version 1.0

Elevation

Spatial scope

National

Access constraints: Other restrictions

Other constraints: no limitations to public access

Use limitation: Zugangs- und Nutzungsbedingungen

Use constraints: Other restrictions

Other constraints: gebührenpflichtig

Spatial representation type: Vector

Language: Deutsch

Character set: UTF8

Topic category

Elevation

Extent

Description: Liechtenstein

Reference system identifier: http://www.opengis.net/def/crs/EPSG/0/2056

Reference system identifier: http://www.opengis.net/def/crs/EPSG/0/4936

Reference system identifier: http://www.opengis.net/def/crs/EPSG/0/21782

Topology level: Geometry only

Geometric object type: Point

Distribution format

Name	Version
GRID ASCII (XYZ)
AutoCAD DXF (DXF)
ESRI Shapefile (SHP)
INTERLIS 1 (ITF)
GRID ASCII (XYZ)

Distributor contact

Organisation name	Individual name	Electronic mail address	Role
Surveying and Geoinformation Division		vermessung@llv.li	Point of contact

OnLine resource

Protocol	Linkage	Name
WWW:LINK	https://www.llv.li/inhalt/1627/amtsstellen/datenausgabe	Homepage ATG, Datenausgabestelle

Hierarchy level: Dataset

Conformance result

Date (Publication): 2010-12-08

Explanation: nicht geprüft

Pass: Yes

Statement: Flugzeuggestütztes Laserscanning

Included with dataset

Date (Creation): 2010-05-20

Metadata

File identifier: 7e312168-ea61-46d1-80fc-0db12742f046 XML

Metadata language: Deutsch

Character set: UTF8

Hierarchy level: Dataset

Date stamp: 2023-03-07T10:15:24.327Z

Metadata standard name: GM03 2+

Metadata author

Organisation name	Individual name	Electronic mail address	Role
Surveying and Geoinformation Division		vermessung@llv.li	Point of contact

Other language

Language	Character encoding
French	UTF8
Italian	UTF8
English	UTF8
German	UTF8
